SECTION 4
4-82
Cab - Fuses box (B)
Engine compartment
FB.1 10A Optional: rotary light
FB.2 10A Optional: cab rear working floodlamps
FB.3 10A Front cab working floodlamps
FB.4 10A Screen wiper and glasses wash pump
FB.5 5A Cab inner light
FB.6 7.5A Voltage supply for 24V/12V radio and socket transformer
FB.7 2A Voltage supply for display and key-pad module in the cab
FB.8 5A Optional: frequency switching valve
FB.9 5A Lights and switches function
FB.10 - Free
FB.11 - Free
FB.12 - Free
FB.13 - Free
FB.14 - Free
FB.15 - Free
FB.16 - Free
F20 125A Grid-Heater
