Case WX145 - Page 61

SECTION 2
2-2
Ref. Description Operation Symbol
1
Rotary knob/
selector
Blower
Activates the blower and has 3-speed stages: 1, 2,
3.
2 White button
Air conditioner
(optional)
Activates/deactivates the air recirculation.
3 Blue button
Air conditioner
(optional)
Activation/deactivation of air conditioner (ON/
OFF).
4
Rotary knob/
selector
Heating
Sets the heating power:
completely to the left - low heating power (blue);
completely to the right - high heating power (red).
5 Push-button
Stabilizer
(optional)
Rear right stabilizer control.
6 Push-button
Stabilizer
(optional)
Rear left stabilizer control.
City Stabilizer
(optional)
City stabilizer control.
7 Push-button
Stabilizer
(optional)
Front left stabilizer control.
Blade (optional) Blade control.
8 Push-button
Stabilizer
(optional)
Front right stabilizer control.
