CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 173
Communication information
Digital Input 2 [522] to Digital Input
8 [528]
Same function as “DigIn 1[521]”. Default function for
DigIn 8 is Reset. For DigIn 3 to 7 the default function is
Off.
Communication information
Reset 9
Reset command. To reset a Trip condition
and to enable the Autoreset function.
Preset Ctrl1 10 To select the Preset Reference.
Preset Ctrl2 11 To select the Preset Reference.
Preset Ctrl3 12 To select the Preset Reference.
MotPot Up 13
Increases the internal reference value
according to the set AccMotPot time
[333]. Has the same function as a “real”
motor potentiometer, see Fig. 110.
MotPot
Down
14
Decreases the internal reference value
according to the set DecMotPot time
[334]. See MotPot Up.
Pump1
Feedb
15
Feedback input pump1 for Pump/Fan
control and informs about the status of the
auxiliary connected pump/fan.
Pump2
Feedb
16
Feedback input pump 2 for Pump/Fan
control and informs about the status of the
auxiliary connected pump/fan.
Pump3
Feedb
17
Feedback input pump3 for Pump/Fan
control and informs about the status of the
auxiliary connected pump/fan.
Pump4
Feedb
18
Feedback input pump 4 for Pump/Fan
control and informs about the status of the
auxiliary connected pump/fan.
Pump5
Feedb
19
Feedback input pump5 for Pump/Fan
control and informs about the status of the
auxiliary connected pump/fan.
Pump6
Feedb
20
Feedback input pump 6 for Pump/Fan
control and informs about the status of the
auxiliary connected pump/fan.
Timer 1 21
Timer 1 Delay [643] will be activated on
the rising edge of this signal.
Timer 2 22
Timer 2 Delay [653] will be activated on
the rising edge of this signal.
Set Ctrl 1 23
Activates other parameter set. See Table
37 for selection possibilities.
Set Ctrl 2 24
Activates other parameter set. See Table
37 for selection possibilities.
Mot
PreMag
25
Pre-magnetises the motor. Used for faster
motor start.
Jog 26
To activate the Jog function. Gives a Run
command with the set Jog speed and
Direction, page 138.
Ext Mot
Temp
27
Be aware that if there is nothing
connected to the input, the AC drive will
trip at
“External Motor Temp” immediately.
NOTE: The External Motor Temp is active
low.
Loc/Rem 28
Activate local mode defined in [2171] and
[2172].
AnIn select 29
Activate/deactivate analogue inputs
defined in [513A], [516A], [519A] and
[51CA]
LC Level 30
Liquid cooling low level signal.
NOTE: The Liquid Cooling Level is active
low.
Brk Ackn 31
Brake acknowledge input for Brake Fault
control. Function is activated via this
selection see menu [33H] page 133
Sleep 32
Possible to enter sleep mode through
DigIn
NOTE: For bipol function, input RunR and RunL
needs to be active and “Rotation [219]” must be set
to “R+L”.
Modbus Instance no/DeviceNet no: 43241
Profibus slot/index 169/145
EtherCAT and CANopen index (hex) 4ca9
Profinet IO index 19625
Fieldbus format UInt
Modbus format UInt
Ta b l e 3 7
Parameter Set Set Ctrl 1 Set Ctrl 2
A00
B10
C01
D11
NOTE: To activate the parameter set selection, menu
241 must be set to DigIn.
522 DigIn 2
Default: RunR
Selection: Same as in menu [521]
Modbus Instance no/DeviceNet no: 43242 – 43248
Profibus slot/index 169/146 – 169/152
EtherCAT and CANopen index (hex) 4caa - 4cb0
Profinet IO index 19626 - 19632
Fieldbus format UInt
Modbus format UInt
