Managing Ports
218 Check Point UTM-1 Edge User Guide
Resetting Ports to Defaults
You can reset the UTM-1 appliance's ports to their default link configurations ("Automatic
Detection") and default assignments (shown in the following table).
Table 41: Default Port Assignments
Port Default Assignment
LAN 1-8 LAN
DMZ / WAN2 DMZ
WAN This port is always assigned to the WAN.
ADSL This port is always assigned to the ADSL connection.
Serial Console
Note: When you reset ports to their defaults, all currently-established connections
that are not supported by the default settings may be broken. For example, if you
were using the DMZ/WAN2 port as WAN2, the port reverts to its DMZ assignment,
and the secondary Internet connection moves to the WAN or ADSL port.
