The UTM-1 Edge X Series and UTM-1 Edge W Series
Chapter 1: Introduction 31
Table 12: UTM-1 Edge W Appliance Rear Panel Elements
Label Description
PWR A power jack used for supplying power to the unit. Connect the supplied power
supply to this jack.
RESET A button used for rebooting the UTM-1 appliance or resetting the UTM-1
appliance to its factory defaults. You need to use a pointed object to press this
button.
• Short press. Reboots the UTM-1 appliance
• Long press (7 seconds). Resets the UTM-1 appliance to its factory
defaults, and resets your firmware to the version that shipped with the
UTM-1 appliance. This results in the loss of all security services and
passwords and reverting to the factory default firmware. You will have
to re-configure your UTM-1 appliance.
Do not reset the unit without consulting your system administrator.
USB Two USB 2.0 ports used for connecting USB-based printers or modems
Serial A serial (RS-232) port used for connecting computers in order to access the
UTM-1 CLI (Command Line Interface), or for connecting an external dialup
modem.
Depending on the appliance model, this port may have either a DB9 RS232
connector, or an RJ-45 connector. In models with an RJ-45 connector, an RJ-45
to DB9 converter is supplied for your convenience.
Warning: Do not connect an Ethernet cable to the RJ-45 serial port.
WAN Wide Area Network: An Ethernet port (RJ-45) used for connecting your
broadband modem, a wide area network router, or a network leading to the
Internet.
