3-12
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 3 Using the ASDM User Interface
Common Buttons
device; however, that device must run the same version of ASDM that you are currently running. To
display the pane fully, you must have at least two devices listed. This feature is available in routed and
transparent modes, and in the single, multiple, and system contexts.
To use this pane to connect to another device, perform the following steps:
Step 1 Click Add to add another device to the list.
The Add Device dialog box appears.
Step 2 In the Device/IP Address/Name field, type the device name or IP address of the device, and then click
OK.
Step 3 Click Delete to remove a selected device from the list.
Step 4 Click Connect to connect to another device.
The Enter Network Password dialog box appears.
Step 5 Type your username and password in the applicable fields, and then click Login.
Common Buttons
Many ASDM panes include buttons that are listed in the following table. Click the applicable button to
complete the desired task:
Button Description
Apply Sends changes made in ASDM to the adaptive security appliance and applies
them to the running configuration.
Save Writes a copy of the running configuration to flash memory.
Reset Discards changes and reverts to the information displayed before changes
were made or the last time that you clicked Refresh or Apply. After you click
Reset, click Refresh to make sure that information from the current running
configuration appears.
Restore Default Clears the selected settings and returns to the default settings.
Cancel Discards changes and returns to the previous pane.
Enable Displays read-only statistics for a feature.
Close Closes an open dialog box.
Clear Remove information from a field, or remove a check from a check box.
Back Returns to the previous pane.
Forward Goes to the next pane.
Help Displays help for the selected pane or dialog box.
