7-27
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 7 Using the Startup Wizard
Configuring IPv6 Static Neighbors
Viewing and Clearing Dynamic Neighbors
When a host or node communicates with a neighbor, the neighbor is added to the neighbor discovery
cache. The neighbor is removed from the cache when there is no longer any communication with the
neighbor.
To view dynamically discovered neighbors and to clear neighbors from the IPv6 Neighbor Discovery
Cache, perform the following steps:
Step 1 Choose Monitoring > Interface Graphs > IPv6 Neighbor Discovery Cache.
You can view all static and dynamically discovered neighbors from the IPv6 Neighbor Discovery Cache
pane.
Step 2 To clear all dynamically discovered neighbors from the cache, click Clear Dynamic Neighbor Entries.
The neighbor information is removed from the cache.
Note This procedure clears only dynamically discovered neighbors from the cache; it does not clear
static neighbors. To clear static neighbors, see the “Deleting Static Neighbors” section on
page 7-26.
Interface Configuration
To configure the remaining interfaces and enable traffic between two or more interfaces, perform the
following steps:
Step 1 To change the configuration of the interface in the Edit Interface dialog box, click Edit.
Step 2 To enable traffic between two or more interfaces with the same security level, check the Enable traffic
between two or more interfaces with the same security level check box.
Note IP address-related fields are not available in transparent mode.
Step 3 Click Next to continue.
Outside Interface Configuration - PPPoE
To configure the outside interface by obtaining an IP address from a PPPoE server, perform the following
steps:
Step 1 Enter the name of the group. You must specify a group name to proceed.
Step 2 In the User Authentication area, enter the following information:
• The PPPoE username.
To Next Page
