Cisco 5510 - ASA SSL / IPsec VPN Edition Configuration Guide

3-22
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 3 Using the ASDM User Interface
Home Pane (Single Mode and Context)
Figure 3-5 shows the elements of the Content Security tab.
Figure 3-5 Content Security Tab
Legend
Intrusion Prevention Tab
The Intrusion Prevention tab lets you view important information about IPS. This tab appears only when
you have IPS software running on the AIP SSM that is installed on the adaptive security appliance.
To connect to the IPS software on the AIP SSM, perform the following steps:
Step 1 In the main ASDM application window, click the Intrusion Prevention tab.
Step 2 In the Connecting to IPS dialog box, choose one of the following options:
1
2
3
4
5
252948
GUI Element Description
1 CSC SSM Information pane.
2 Threat Summary pane. Shows aggregated data about threats detected by the CSC SSM,
including the following threat types: Virus, Spyware, URL Filtered or Blocked, Spam.
Blocked, Files Blocked, and Damage Control Services.
3 System Resources Status pane.
4 Email Scan pane. The graphs display data in ten-second intervals.
5 Latest CSC Security Events pane.
