3-23
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 3 Using the ASDM User Interface
Home Pane (Single Mode and Context)
• Management IP Address, which connects to the IP address of the management port on the SSM.
• Other IP Address or Hostname, which connects to an alternate IP address or hostname on the SSM.
Step 3 Enter the port number in the Port field, and then click Continue.
Step 4 In the Enter Network Password dialog box, type your username and password in the applicable fields,
and then click Login.
For more information about intrusion prevention, see Configuring the IPS Application on the
AIP SSM and SSC.
Figure 3-6 shows the elements of the Health Dashboard tab, located on the Intrusion Prevention tab.
Figure 3-6 Intrusion Prevention Tab (Health Dashboard)
Legend
247351
1 23 4 5
GUI Element Description
1 Sensor Information pane.
2 Sensor Health pane.
3 CPU, Memory, and Load pane.
4 Interface Status pane.
5 Licensing pane.
