3-17
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 3 Using the ASDM User Interface
Home Pane (Single Mode and Context)
Legend
Device Information Pane
The Device Information pane includes two tabs that show device information:
• General Tab, page 3-17
• License Tab, page 3-17
General Tab
This tab shows basic information about the adaptive security appliance, including the hostname,
software version, and RAM.
Note If you do not have enough memory to upgrade to the most current release of the adaptive security
appliance, the Memory Insufficient Warning dialog box appears. Follow the directions that appear in this
dialog box to continue using the adaptive security appliance and ASDM in a supported manner. Click
OK to close this dialog box.
License Tab
This tab shows a subset of licensed features. To view detailed license information, or to enter a new
activation key, click More Licenses; the Configuration > Device Management > Licensing > Activation
Key pane appears. See Chapter 4, “Managing Feature Licenses.”
Interface Status Pane
This pane shows the status of each interface. If you select an interface row, the input and output
throughput in Kbps displays below the table.
VPN Sessions Pane
This pane shows the VPN tunnel status. Click Details to go to the Monitoring > VPN > VPN Statistics
> Sessions pane.
GUI Element Description
1 Device Information Pane, page 3-17
2 Interface Status Pane, page 3-17
3 VPN Sessions Pane, page 3-17
4 Traffic Status Pane, page 3-18
5 System Resources Status Pane, page 3-18
6 Traffic Status Pane, page 3-18
See
Figure 3-3
Latest ASDM Syslog Messages Pane, page 3-18
