7-10
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 7 Using the Startup Wizard
Startup Wizard Screens for the ASA 5505 Adaptive Security Appliance
– Choose a subnet mask for the Internet interface from the drop-down list.
• To set the default routing using the PPPoE server, check the Obtain default route using PPPoE
check box.
Step 5 Click Next to continue.
Step 11 - Home Interface Configuration - PPPoE
Note For all ASA 5500 series models except ASA 5505, with a full license, the adaptive security appliance
supports up to five interfaces, with a maximum of three outside interfaces. In restricted mode, the
adaptive security appliance supports up to three interfaces, and in transparent mode, the adaptive security
appliance supports up to two interfaces. After you have created the maximum number of interfaces, or
the maximum number of interfaces has already been named, you may not be able to create a new VLAN,
and must select an existing one.
Step 1 Enter the name of the group on the PPPoE server. You must specify a group name to proceed.
Step 2 In the User Authentication area, do the following:
a. Enter your username on the PPPoE server.
b. Enter your password on the PPPoE server.
c. Enter the PPPoE password that you entered.
Step 3 In the Authentication Method area, choose one of the following:
• To use PAP authentication, click PAP.
• To use CHAP authentication., click CHAP.
• To use MS-CHAP authentication, click MS-CHAP.
Step 4 In the IP Address area, choose one of the following:
• Click the Obtain an IP address using PPPoE radio button to obtain an IP address for the DMZ
interface from the PPPoE server. This option is not visible in transparent mode.
• Enter an IP address for the DMZ interface. This option is not visible in transparent mode.
– Enter the IP address that you want to use for the DMZ interface.
– Choose a subnet mask for the DMZ interface from the drop-down list.
• To set the default routing using the PPPoE server, check the Obtain default route using PPPoE
check box.
Step 5 Click Next to continue.
Step 12 - General Interface Configuration
Restricted traffic is not an optional configuration. If you only have a restricted license, you must restrict
traffic from one interface to any of the other interfaces. The Restrict Traffic area fields are hidden if you
have a full license or if the device is in transparent mode.
