7-7
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 7 Using the Startup Wizard
Startup Wizard Screens for the ASA 5505 Adaptive Security Appliance
b. To create a new outside VLAN, check the Create a VLAN check box.
c. To enable the outside VLAN, check the Enable VLAN check box.
Step 2 In the Inside VLAN or Business VLAN area, do the following:
a. From the Choose a VLAN drop-down list, choose a predefined inside VLAN by number.
b. To create a new inside VLAN, check the Create a VLAN check box.
c. To enable the inside VLAN, check the Enable VLAN check box.
Step 3 In the DMZ VLAN or Home VLAN (Optional) area, do the following:
a. From the Choose a VLAN drop-down list, choose a predefined inside VLAN by number.
b. To create a new inside VLAN, check the Create a VLAN check box.
• To disable configuration of this VLAN, check the Do not configure check box.
Step 4 Click Next to continue.
Step 7 - Switch Port Allocation
This screen lets you allocate switch ports to outside (Internet), inside (Business), or DMZ (Home)
interfaces. The DMZ interface is not available in transparent mode. You must add the ports to the
associated VLANs. By default, all switch ports begin with VLAN1.
Step 1 In the Switch Ports for Outside VLAN (vlanid) or Switch Ports for Internet VLAN (vlanid) area, do the
following:
a. Choose a port to add or remove from the available list of ports.
b. Choose a port to add or remove from the allocated list of ports.
c. To add a port to the available or allocated list of ports, click Add.
d. To remove a port from the available or allocated list of ports, click Remove.
Step 2 In the Switch Ports for Inside VLAN (vlanid) or Switch Ports for Business VLAN (vlanid) area, do the
following:
a. Choose a port to add or remove from the available list of ports.
b. Choose a port to add or remove from the allocated list of ports.
c. To add a port to the available or allocated list of ports, click Add.
d. To remove a port from the available or allocated list of ports, click Remove.
Step 3 In the Switch Ports for DMZ VLAN (vlanid) or Switch Ports for Home VLAN (vlanid) area, do the
following:
a. Choose a port to add or remove from the available list of ports.
b. Choose a port to add or remove from the allocated list of ports.
c. To add a port to the available or allocated list of ports, click Add.
d. To remove a port from the available or allocated list of ports, click Remove.
Step 4 Click Next to continue.
