7-8
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 7 Using the Startup Wizard
Startup Wizard Screens for the ASA 5505 Adaptive Security Appliance
Step 8 - Interface IP Address Configuration
To configure the interface through a PPPoE server, a DHCP server, or by specifying a particular IP
address and subnet mask, perform the following steps:
Step 1 In the Outside IP Address or Internet IP Address area, do one of the following:
• To specify an outside IP address, click the Use the following IP address radio button.
• Enter the specific outside IP address and choose the subnet mask from the drop-down list.
• To obtain an outside IP address from a DHCP server, click the Use DHCP radio button.
• To obtain the default route for an outside IP address from a DHCP server, check the Obtain default
rote using DHCP check box.
• To obtain an outside IP address from a PPPoE server, click the Use PPPoE radio button.
Step 2 In the Inside IP Address or Business IP Address area, do one of the following:
• To specify an inside IP address, click the Use the following IP address radio button.
• Enter the specific inside IP address and choose the subnet mask from the drop-down list.
• To obtain an inside IP address from a DHCP server, click the Use DHCP radio button.
• To obtain the default route for an inside IP address from a DHCP server, check the Obtain default
rote using DHCP check box.
• To obtain an inside IP address from a PPPoE server, click the Use PPPoE radio button.
In the DMZ IP Address or Home IP Address area, choose one of the following:
• To specify a DMZ IP address, click the Use the following IP address radio button, then enter the
specific DMZ IP address and choose the subnet mask from the drop-down list.
• To obtain a DMZ IP address from a DHCP server, click the Use DHCP radio button.
• To obtain a DMZ IP address from a PPPoE server, click the Use PPPoE radio button.
Step 3 Click Next to continue.
Step 9 - Internet Interface Configuration - PPPoE
Note For all ASA 5500 series models except ASA 5505, with a full license, the adaptive security appliance
supports up to five interfaces, with a maximum of three outside interfaces. In restricted mode, the
adaptive security appliance supports up to three interfaces, and in transparent mode, the adaptive security
appliance supports up to two interfaces. After you have created the maximum number of interfaces, or
the maximum number of interfaces has already been named, you may not be able to create a new VLAN,
and must select an existing one.
Step 1 Specify the name of the group on the PPPoE server. You must specify a group name to proceed.
Step 2 In the User Authentication area, do the following:
a. Specify your username on the PPPoE server.
b. Specify your password on the PPPoE server.
