64-66
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 64 General VPN Setup
Configuring Clientless SSL VPN Connections
–
Use the entire DN as the username—Enables or disables the requirement to use the entire DN
as the username.
–
Specify individual DN fields as the username. You can select both the primary DN field, for
which the default is CN (Common Name) and the secondary DN field, for which the default is
OU (Organization Unit).
–
Primary Field—Selects the first field to use in the username.
–
Secondary Field—Selects the second field to use in the username.
Modes
The following table shows the modes in which this feature is available:
Assign Authorization Server Group to Interface
This dialog box lets you associate an interface with a AAA server group. The results appear in the table
on the Authorization dialog box.
Fields
• Interface—Selects an interface, DMZ, Outside, or Inside. The default is DMZ.
• Server Group—Selects a server group to assign to the selected interface. The default is LOCAL.
• Manage—Opens the Configure AAA Server Groups dialog box.
Modes
The following table shows the modes in which this feature is available:
Add or Edit SSL VPN Connections > Advanced > SSL VPN
This dialog box lets you configure attributes that affect what the remote user sees upon login.
Fields
• Portal Page Customization—Configures the look and feel of the user login page by specifying which
preconfigured customization attributes to apply. The default is DfltCustomization.
• Enable the display of Radius Reject-Message on the login screen—Select this check box to display
the RADIUS-reject message on the login dialog box when authentication is rejected.
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
• — • ——
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
• — • ——
