64-89
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 64 General VPN Setup
Mapping Certificates to IPsec or SSL VPN Connection Profiles
Modes
The following table shows the modes in which this feature is available:
Add/Edit Tunnel Group > General > Advanced
The Add or Edit Tunnel Group dialog box, General, Advanced dialog box, lets you configure the
following interface-specific attributes:
• Interface-Specific Authentication Server Groups—Lets you configure an interface and server group
for authentication.
–
Interface—Lists available interfaces for selection.
–
Server Group—Lists authentication server groups available for this interface.
–
Use LOCAL if server group fails—Enables or disables fallback to the LOCAL database if the
server group fails.
–
Add—Adds the association between the selected available interface and the authentication
server group to the assigned list.
–
Remove—Moves the selected interface and authentication server group association from the
assigned list to the available list.
–
Interface/Server Group/Use Fallback—Show the selections you have added to the assigned list.
• Interface-Specific Client IP Address Pools—-Lets you specify an interface and Client IP address
pool. You can have up to 6 pools.
–
Interface—Lists the available interfaces to add.
–
Address Pool—Lists address pools available to associate with this interface.
–
Add—Adds the association between the selected available interface and the client IP address
pool to the assigned list.
–
Remove—Moves the selected interface/address pool association from the assigned list to the
available list.
–
Interface/Address Pool—Shows the selections you have added to the assigned list.
Modes
The following table shows the modes in which this feature is available:
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
• — • ——
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
• — • ——
