64-100
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 64 General VPN Setup
Mapping Certificates to IPsec or SSL VPN Connection Profiles
Fields
• Interface—Select the interface to which you want to assign an address pool. The default is DMZ.
• Address Pools—Specify an address pool to assign to the specified interface.
• Select—Opens the Select Address Pools dialog box, in which you can select one or more address
pools to assign to this interface. Your selection appears in the Address Pools field of the Assign
Address Pools to Interface dialog box.
Select Address Pools
The Select Address Pools dialog box shows the pool name, starting and ending addresses, and subnet
mask of address pools available for client address assignment and lets you add, edit, or delete entries
from that list.
Fields
• Add—Opens the Add IP Pool dialog box, on which you can configure a new IP address pool.
• Edit—Opens the Edit IP Pool dialog box, on which you can modify a selected IP address pool.
• Delete—Removes the selected address pool. There is no confirmation or undo.
• Assign—Displays the address pool names that remained assigned to the interface. Double-click each
unassigned pool you want to add to the interface. The Assign field updates the list of pool
assignments.
Modes
The following table shows the modes in which this feature is available:
Add or Edit an IP Address Pool
Configures or modifies an IP address pool.
Fields
• Name—Specifies the name assigned to the IP address pool.
• Starting IP Address—Specifies the first IP address in the pool.
• Ending IP Address—Specifies the last IP address in the pool.
• Subnet Mask—Selects the subnet mask to apply to the addresses in the pool.
Modes
The following table shows the modes in which this feature is available:
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
• — • ——
