38-18
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 38 Configuring Inspection for Voice and Video Protocols
MGCP Inspection
Fields
• Name—When adding an MGCP map, enter the name of the MGCP map. When editing an MGCP
map, the name of the previously configured MGCP map is shown.
• Description—Enter the description of the MGCP map, up to 200 characters in length.
• Command Queue—Tab that lets you specify the permitted queue size for MGCP commands.
–
Command Queue Size—Specifies the maximum number of commands to queue. The valid
range is from 1 to 2147483647.
• Gateways and Call Agents—Tab that lets you configure groups of gateways and call agents for this
map.
–
Group ID—Identifies the ID of the call agent group. A call agent group associates one or more
call agents with one or more MGCP media gateways. The gateway IP address can only be
associated with one group ID. You cannot use the same gateway with different group IDs. The
valid range is from 0 to 2147483647Criterion—Shows the criterion of the inspection.
–
Gateways—Identifies the IP address of the media gateway that is controlled by the associated
call agent. A media gateway is typically a network element that provides conversion between
the audio signals carried on telephone circuits and data packets carried over the Internet or over
other packet networks. Normally, a gateway sends commands to the default MGCP port for call
agents, 2727.
–
Call Agents—Identifies the IP address of a call agent that controls the MGCP media gateways
in the call agent group. Normally, a call agent sends commands to the default MGCP port for
gateways, 2427.
–
Add—Displays the Add MGCP Group dialog box, which you can use to define a new MGCP
group of gateways and call agents.
–
Edit—Displays the Edit MGCP dialog box, which you can use to modify the MGCP group
selected in the Gateways and Call Agents table.
–
Delete—Deletes the MGCP group selected in the Gateways and Call Agents table.
Modes
The following table shows the modes in which this feature is available:
Add/Edit MGCP Group
The Add/Edit MGCP Group dialog box lets you define the configuration of an MGCP group that will be
used when MGCP application inspection is enabled.
Fields
• Group ID—Specifies the ID of the call agent group. A call agent group associates one or more call
agents with one or more MGCP media gateways. The valid range is from 0 to 2147483647.
Firewall Mode Security Context
Routed Transparent Single
Multiple
Context System
••••—
