42-13
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 42 Using the Cisco Unified Communication Wizard
Configuring the UC-IME by using the Unified Communication Wizard
Step 4 In the Ticket Password field, enter a minimum of 10 and a maximum of 64 printable character from the
US-ASCII character set. The allowed characters include 0x21 to 0x73 inclusive, and exclude the space
character. The ticket password is stored onto flash.
Note We recommend a password of at least 20 characters. Only one password can be configured at a
time.
The epoch and password that you configure on the adaptive security appliance must match the epoch and
password configured on the Cisco Intercompany Media Engine server. See the Cisco Intercompany
Media Engine server documentation for information.
Step 5 In the Confirm Password field, reenter the password.
Step 6 In the X.509 Subject Name field, enter the distinguished name (DN) of the local enterprise. The name
that you enter must match the name configured for the Cisco Unified Communications servers in the
cluster. See the Cisco Unified Communications server documentation for information.
Step 7 Click Next.
Adding a Cisco Unified Communications Manager Server for the UC-IME Proxy
You must include an entry for each Cisco UCM in the cluster with Cisco Intercompany Media Engine
Proxy that has a SIP trunk enabled.
Step 1 Enter the private IP address and port number (in the range 5000-6000) for the Cisco UCM server.
Step 2 In the Address Translation area, enter the public IP address for the Cisco UCM server.
Step 3 If necessary, enter the port number for the public IP address by clicking the Translate address and port
radio button and entering a number (in the range 5000-6000) in the Port field.
Step 4 In the Security Mode area, click the Secure or Non-secure radio button. Specifying secure for Cisco
UCM or Cisco UCM cluster indicates that Cisco UCM or Cisco UCM cluster is initiating TLS.
If you specify that some of the Cisco UCM servers are operating in secure mode, the Unified
Communications Wizard includes a step in the proxy configuration to generate certificates for the
local-side communication between the adaptive security appliance and that Cisco UCM server. See
Configuring the Local-Side Certificates for the Cisco Intercompany Media Engine Proxy, page 42-15.
Step 5 Click OK.
Configuring the Public Network Settings for the Cisco Intercompany Media
Engine Proxy
The public network configuration depends on the deployment scenario you selected in the topology step
of this wizard. Specifically, when you are configuring the UC-IME proxy as part of an off-path
deployment, this step of the wizard displays fields for address translation, requiring that you specify the
private IP address for the UC-IME proxy. Specifying this private IP address, translates IP addresses for
inbound traffic.
