Chapter 4 Configuring Class Maps and Policy Maps
Class Maps and Policy Map Examples
Step 3 Create a TCP connection parameter map by entering the following commands:
host1/Admin(config)# parameter-map type connection TCP_MAP
host1/Admin(config-parammap-conn)# reserved-bits allow
host1/Admin(config-parammap-conn)# exceed-mss allow
host1/Admin(config-parammap-conn)# nagle
host1/Admin(config-parammap-conn)# set tcp queue-limit 10
host1/Admin(config-parammap-conn)# set tcp syn-retry 3
host1/Admin(config-parammap-conn)# set tcp timeout embryon
ic 60
host1/Admin(config-parammap-conn)# exit
host1/Admin(config)#
Step 4 Create a Layer 3 and Layer 4 policy map to activate the traffic classifications
outlined in the previous steps by entering the following commands:
host1/Admin(config)# policy-map multi-match L4_SLB_POLICY
host1/Admin(config-pmap)# class L
4_SLBVIP_CLASS
host1/Admin(config-pmap-c)# loadb
alance policy L7_SLB_POLICY
host1/Admin(config-pmap-c)# loadb
alance vip inservice
host1/Admin(config-pmap-c)# conne
ction advanced-options TCP_MAP
host1/Admin(config-pmap-c)# exit
host1/Admin(config-pmap)# exit
host1/Admin(config)#
Step 5 Apply the completed policies to interface VLAN 10 by entering the following
commands:
host1/Admin(config)# interface VLAN 10
host1/Admin(config-if)# service-p
olicy input L4_SLB_POLICY
