Chapter 9 Configuring the XML Interface
XML Configuration Quick Start
XML Configuration Quick Start
Table 9-2 provides a quick overview of the steps required to configure XML usage
with the ACE. Each step includes the CLI command required to complete the task.
Ta b l e 9-2 ACE XML Configuration Quick Start
Task and Command Example
1. Enter configuration mode.
host1/Admin# config
Enter configuration commands, one per line. End with CNTL/Z.
host1/Admin(config)#
2. Create a Layer 3 and Layer 4 class map to classify the HTTP or HTTPS
management traffic that can be received by the ACE.
host1/Admin(config)# class-map type management match-all
XML-HTTPS-ALLOW_CLASS
host1/Admin(config-cmap-mgmt)# match proto
col xml-https
source-address 192.168.1.1 255.255.255.255
host1/Admin(config-cmap-mgmt)# exit
3. Configure a Layer 3 and Layer 4 HTTP or HTTPS traffic management
policy.
host1/Admin(config) # policy-map type management first-match
MGMT_XML-HTTPS_POLICY
host1/Admin(config-pmap-mgmt) # class XML-
HTTPS-ALLOW_CLASS
host1/Admin(config-pmap-mgmt-c) # permit
host1/Admin(config-pmap-mgmt-c) # exit
4. Attach the traffic policy to a single interface or globally on all VLAN
interfaces associated with a context, and specify the direction in which the
policy should be applied. For example, to specify an interface VLAN and
apply multiple service policies to the VLAN, enter:
host1/Admin(config)# interface vlan50
host1/Admin(config-if)# ip address 192.168
.10.1 255.255.0.0
host1/Admin(config-if)# service-policy inp
ut
MGMT_XML-HTTPS_POLICY
host1/Admin(config-if)# exit
host1/Admin(config)# exit
