Cisco Catalyst 2950 Software Guide

1-2
Catalyst 2950 Desktop Switch Software Configuration Guide
78-11380-03
Chapter 1 Overview
Features
Table 1-1 Features
Ease of Use and Ease of Deployment
• Cluster Management Suite (CMS) software for simplified switch and switch cluster management through a web
browser, such as Netscape Communicator or Microsoft Internet Explorer, from anywhere in your intranet
• Switch clustering technology used with CMS for
– Unified configuration, monitoring, authentication, and software upgrade of multiple switches (refer to the release
notes for a list of eligible cluster members).
– Automatic discovery of candidate switches and creation of clusters of up to 16 switches that can be managed
through a single IP address.
– Extended discovery of cluster candidates that are not directly connected to the command switch.
• Hot Standby Router Protocol (HSRP) for command-switch redundancy. The redundant command switches used for
HSRP must have compatible software releases.
Note See the “Advantages of Using CMS and Clustering Switches” sectiononpage1-7. Refer to the release notes for the
CMS, cluster hardware, software, and browser requirements.
Performance
• Autosensing of speed on the 10/100 ports and autonegotiation of duplex mode on all switch ports for optimizing
bandwidth
• IEEE 802.3x flow control on Gigabit ports operating in full-duplex mode
• Fast EtherChannel and Gigabit EtherChannel for enhanced fault tolerance and for providing up to 2 Gbps of bandwidth
between switches, routers, and servers
• Support for mini-jumbo frames. The Catalyst 2950 switches running Cisco IOS Release12.1(6)EA2 or later support frame
sizes 1500 to 1530 bytes
• Per-port broadcast storm control for preventing faulty end stations from degrading overall system performance with
broadcast storms
• Port Aggregation Protocol (PAgP) for automatic creation of EtherChannel links
• Internet Group Management Protocol (IGMP) snooping support to limit flooding of IP multicast traffic
• Multicast VLAN registration (MVR) to continuously send multicast streams in a multicast VLAN, but to isolate the
streams from subscriber VLANs for bandwidth and security reasons
• Protected port (private VLAN edge port) option for restricting the forwarding of traffic to designated ports on the same
switch
• Dynamic address learning for enhanced security

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
