Cisco Catalyst 2950 Software Guide

5-20
Catalyst 2950 Desktop Switch Software Configuration Guide
78-11380-03
Chapter 5 Clustering Switches
Creating a Switch Cluster
Creating a Cluster Standby Group
The cluster standby group members must meet the requirements described in the “Standby Command
Switch Characteristics” sectiononpage5-3and “HSRPandStandbyCommandSwitches” section on
page 5-10. To create a cluster standby group, select Cluster > Standby Command Switches
(Figure 5-10).
Instead of using CMS to add switches to a standby group and to bind the standby group to a cluster, you
can use the standby ip, standby name, standby priority interface configuration commands and the
cluster standby group global configuration command.
Note • When the command switch is a Catalyst 3550 switch, all standby command switches must be
Catalyst 3550 switches or Catalyst 2950 switches running Cisco IOS Release 12.1(6)EA2 or later.
• When the command switch is a Catalyst 2950 switch running Cisco IOS Release 12.1(6)EA2 or
later, all standby command switches must be Catalyst 2950 switches running Cisco IOS
Release 12.1(6)EA2 or later.
• When the Catalyst 2950 command switch is running Cisco IOS Release 12.0(5)WC2 or earlier, the
standby command switches can be these switches also running Cisco IOS Release 12.0(5)WC2 or
earlier: Catalyst 2900 XL, Catalyst 2950, and Catalyst 3500 XL switches.
These abbreviations are appended to the switch host names in the Standby Command Group list to show
their status in the cluster standby group:
• AC—Active command switch
• SC—Standby command switch
• PC—Member of the cluster standby group but not the standby command switch
• HC—Candidate switch that can be added to the cluster standby group
• CC—Command switch when HSRP is disabled
You must enter a virtual IP address for the cluster standby group. This address must be in the same subnet
as the IP addresses of the switch. The group number must be unique within the IP subnet. It can be from
0 to 255, and the default is 0. The group name can have up to 31 characters.
The Standby Command Configuration window uses the default values for the preempt and name
commands that you have set by using the CLI. If you use this window to create the HSRP group, all
switches in the group have the preempt command enabled. You must also provide a name for the group.
Note The HSRP standby hold time interval should be greater than or equal to 3 times the hello time interval.
The default HSRP standby hold time interval is 10 seconds. For more information about the standby hold
time and hello time intervals, refer to the Cisco IOS Release 12.1 documentation set on Cisco.com.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
