10-13
Catalyst 2950 Desktop Switch Software Configuration Guide
78-11380-03
Chapter 10 Configuring the Switch Ports
Understanding the EtherChannel
Figure 10-3 Load Distribution and Forwarding Methods
Default EtherChannel Configuration
Table 10-2 shows the default EtherChannel configuration.
65188
Cisco router
with destination-based
forwarding enabled
EtherChannel
Catalyst 2950 switch
with source-based
forwarding enabled
Table 10-2 Default EtherChannel Configuration
Feature Default Setting
Channel groups None assigned.
PAgP mode No default.
PAgP learn method Aggregate-port learning on all interfaces.
PAgP priority 128 on all interfaces. (Changing this value on
Catalyst 2950 switches has no effect.)
Load balancing Load distribution on the switch is based on the
source-MAC address of the incoming packet.
