Cisco Catalyst 2950 Software Guide

2-24
Catalyst 2950 Desktop Switch Software Configuration Guide
78-11380-03
Chapter 2 Getting Started with CMS
Menus and Toolbar
Table 2-17 Device Popup Menu of a Member or Standby Command-Switch Icon
Popup Menu Option Task
Remove from Cluster
1
1. Available only from a cluster-management session.
Remove a member from the cluster.
Host Name
1
Change the host name of a switch.
Device Manager
2
2. Available from a cluster member switch but not from the command switch.
Launch Device Manager for a switch.
Bandwidth Graphs Display graphs that plot the total bandwidth in use by the switch.
Properties Display information about the device and port on either end of the link and the state of the link.
Table 2-18 Device Popup Menu of a Candidate-Switch Icon (When the Candidate Switch Has an IP Address)
Popup Menu Option Task
Add to Cluster
1
1. Not available in read-only mode. For more information about the read-only and read-write access modes, see the “Access Modes in CMS” section on
page 2-31.
Add a candidate to a cluster.
Device Manager
2
2. Available from a cluster member switch but not from the command switch.
Launch Device Manager for a switch.
Properties Display information about the device and port on either end of the link and the state of the link.
Table 2-19 Device Popup Menu of a Candidate-Switch Icon (When the Candidate Switch Does Not Have an IP Address)
Popup Menu Option Task
Add to Cluster
1
1. Not available in read-only mode. For more information about the read-only and read-write access modes, see the “Access Modes in CMS” section on
page 2-31.
Add a candidate to a cluster.
Properties Display information about the device and port on either end of the link and the state of the link.
Table 2-20 Device Popup Menu of a Neighboring-Device Icon
Popup Menu Option Task
Device Manager
1
1. Available from a cluster member switch but not from the command switch.
Access the web management interface of the device.
Note This option is available on Cisco access points, but not on Cisco IP phones, hubs, routers
and on unknown devices such as some Cisco devices and third-party devices.
Disqualification Code Display the reason why the device could not join the cluster.
Properties Display information about the device and port on either end of the link and the state of the link.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
