131
Configuring PROFINET
Monitoring and Maintaining PROFINET
Monitoring and Maintaining PROFINET
Example
IE5000#show profinet status
State : Enabled
Vlan : 2
Id : Ie5000
Connected : Yes
ReductRatio : 128
GSD Version: Match
Troubleshooting PROFINET
The PLC has LEDs that display red for alarms, and the I/O supervisor software monitors those alarms.
To troubleshoot PROFINET use the debug profinet privileged EXEC command with the keywords shown in Table 20 on
page 131. Be aware that the output of a debug command might cause a serial link to fail. You should use these
commands only under the guidance of a Cisco Technical Support engineer. When you use this command, use Telnet to
access the Cisco IOS command-line interface (CLI) by using Ethernet rather than a serial port.
Additional References
The following sections provide references related to switch administration:
Table 19 Commands for Displaying the PROFINET Configuration
Command Purpose
show profinet sessions Displays the currently connected PROFINET sessions.
show profinet status Displays the status of the PROFINET subsystem.
show lldp neighbor interface x/x detail Displays information about the adjacent interface.
Table 20 Commands for Troubleshooting the PROFINET Configuration
Command Purpose
debug profinet alarm Displays the alarm status (on or off) and content of PROFINET alarms.
debug profinet cyclic Displays information about the time-cycle-based PROFINET Ethernet frames.
debug profinet error Displays the PROFINET session errors.
debug profinet packet ethernet Displays information about the PROFINET Ethernet packets.
debug profinet packet udp Displays information about the PROFINET Upper Layer Data Protocol (UDP)
packets.
debug profinet platform Displays information about the interaction between the Cisco IOS software and
PROFINET.
debug profinet topology Displays the PROFINET topology packets received.
debug profinet trace Displays a group of traced debug output logs.
