Cisco IE-5000 User Manual

102
Configuring Switch Clusters
Additional References
If a cluster member switch has its own IP address and community strings, they can be used in addition to the access
provided by the cluster command switch.
Figure 13 SNMP Management for a Cluster
Additional References
The following sections provide references related to switch administration:
Tra p
Tra p
Tra p
Command switch
Trap 1, Trap 2, Trap 3
Member 1 Member 2 Member 3
33020
SNMP Manager

Cisco IE-5000 Specifications

General

Model	IE-5000
Category	Industrial Ethernet Switch
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16, 000 entries
Ports	16 or 24 10/100/1000 ports
Uplink Ports	4 SFP ports
Operating Temperature	-40°C to 70°C
Power Supply	Dual redundant power supplies
Mounting	DIN rail
Management	Web GUI, CLI, SNMP
Input Voltage	24 VDC or 110/220 VAC
Layer	Layer 2/3
Jumbo Frame Support	Up to 9216 bytes
