Cisco IE-5000 User Manual

479
Configuring SPAN and RSPAN
How to Configure SPAN and RSPAN
Creating an RSPAN Source Session
Command Purpose
1. configure terminal Enters global configuration mode.
2. no monitor session {session_number | all |
local | remote}
Removes any existing RSPAN configuration for the session.
session_number—The range is 1 to 68.
all—Removes all RSPAN sessions
local—Removes all local sessions
remote—Removes all remote SPAN sessions.
3. monitor session session_number source
{interface interface-id | vlan vlan-id} [, | -]
[both | rx | tx]
Specifies the RSPAN session and the source port (monitored port).
session_number—The range is 1 to 68.
Enter a source port or source VLAN for the RSPAN session:
 interface-id—Specifies the source port to monitor. Valid
interfaces include physical interfaces and port-channel logical
interfaces (port-channel port-channel-number). Valid
port-channel numbers are 1 to 10.
 vlan-id—Specifies the source VLAN to monitor. The range is 1 to
4096 (excluding the RSPAN VLAN).
A single session can include multiple sources (ports or VLANs),
defined in a series of commands, but you cannot combine
source ports and source VLANs in one session.
(Optional) [, | -]—Specifies a series or range of interfaces. Enter a
space before and after the comma; enter a space before and after
the hyphen.
(Optional) Specify the direction of traffic to monitor. If you do not
specify a traffic direction, the source interface sends both sent and
received traffic.
 both—Monitors both received and sent traffic.
 rx—Monitors received traffic.
 tx—Monitors sent traffic.
4. monitor session session_number
destination remote vlan vlan-id
Specifies the RSPAN session and the destination RSPAN VLAN.
session_number—Enters the number defined in Step 3.
vlan-id—Specifies the source RSPAN VLAN to monitor.
5. end Returns to privileged EXEC mode.
6. show monitor [session session_number]
show running-config
Verifies the configuration.
7. copy running-config startup-config (Optional) Saves the configuration in the configuration file.

Cisco IE-5000 Specifications

General

Model	IE-5000
Category	Industrial Ethernet Switch
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16, 000 entries
Ports	16 or 24 10/100/1000 ports
Uplink Ports	4 SFP ports
Operating Temperature	-40°C to 70°C
Power Supply	Dual redundant power supplies
Mounting	DIN rail
Management	Web GUI, CLI, SNMP
Input Voltage	24 VDC or 110/220 VAC
Layer	Layer 2/3
Jumbo Frame Support	Up to 9216 bytes
