Configuring SPAN and RSPAN
How to Configure SPAN and RSPAN
Creating a Local SPAN Session and Configuring Incoming Traffic
4. monitor session session_number
destination {interface interface-id [, | -]
[encapsulation replicate]}
Specifies the SPAN session and the destination port (monitoring
port).
session_number—Specifies the session number entered in step 3.
Note: For local SPAN, you must use the same session number for the
source and destination interfaces.
 interface-id—Specifies the destination port. The destination
interface must be a physical port; it cannot be an EtherChannel,
and it cannot be a VLAN.
 (Optional) [, | -]—Specifies a series or range of interfaces. Enter
a space before and after the comma; enter a space before and
after the hyphen.
 (Optional) encapsulation replicate—Specifies that the
destination interface replicates the source interface
encapsulation method. If not selected, the default is to send
packets in native form (untagged).
Note: You can use monitor session session_number destination
command multiple times to configure multiple destination ports.
5. end Returns to privileged EXEC mode.
Command Purpose
Command Purpose
1. configure terminal Enters global configuration mode.
2. no monitor session {session_number | all |
local | remote}
Removes any existing SPAN configuration for the session.

Cisco IE-5000 Specifications

General

Model	IE-5000
Category	Industrial Ethernet Switch
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16, 000 entries
Ports	16 or 24 10/100/1000 ports
Uplink Ports	4 SFP ports
Operating Temperature	-40°C to 70°C
Power Supply	Dual redundant power supplies
Mounting	DIN rail
Management	Web GUI, CLI, SNMP
Input Voltage	24 VDC or 110/220 VAC
Layer	Layer 2/3
Jumbo Frame Support	Up to 9216 bytes
