Configuring IEEE 802.1x Port-Based Authentication
Information About Configuring IEEE 802.1x Port-Based Authentication
Authentication Manager
Port-Based Authentication Methods
Table 29 on page 194 lists the authentication methods supported in these host modes:
 Single host—Only one data or voice host (client) can be authenticated on a port.
 Multiple host—Multiple data hosts can be authenticated on the same port. (If a port becomes unauthorized in
multiple-host mode, the switch denies network access to all of the attached clients.)
 Multidomain authentication (MDA)—Both a data device and voice device can be authenticated on the same switch
port. The port is divided into a data domain and a voice domain.
 Multiple authentication—Multiple hosts can authenticate on the data VLAN. This mode also allows one client on the
VLAN if a voice VLAN is configured.
Table 29 802.1x Features
Authentication Method Mode
Single Host Multiple Host MDA
1
Multiple
Authentication
2
802.1x VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
MAC authentication bypass VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
Standalone web authentication Proxy ACL, Filter-Id attribute, downloadable ACL
2
NAC Layer 2 IP validation Filter-Id attribute
Downloadable ACL
Redirect URL
Filter-Id attribute
Downloadable ACL
Redirect URL
Filter-Id attribute
Downloadable ACL
Redirect URL
Filter-Id attribute
3
Downloadable ACL
Redirect URL
Web authentication as fallback
method
3
Proxy ACL
Filter-Id attribute
Downloadable ACL
Proxy ACL
Filter-Id attribute
Downloadable ACL
Proxy ACL
Filter-Id attribute
Downloadable ACL
Proxy ACL
3
Filter-Id attribute
Downloadable ACL
1. MDA = Multidomain authentication.
2. Also referred to as multiauth.
3. For clients that do not support 802.1x authentication.

Cisco IE-5000 Specifications

General

Model	IE-5000
Category	Industrial Ethernet Switch
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16, 000 entries
Ports	16 or 24 10/100/1000 ports
Uplink Ports	4 SFP ports
Operating Temperature	-40°C to 70°C
Power Supply	Dual redundant power supplies
Mounting	DIN rail
Management	Web GUI, CLI, SNMP
Input Voltage	24 VDC or 110/220 VAC
Layer	Layer 2/3
Jumbo Frame Support	Up to 9216 bytes
