Configuring SDM Templates
Information About Configuring SDM Templates
Table 23 IP Services license SDM Templates
Table 24 Lanbase license SDM Template
The first eight rows in the tables (unicast MAC addresses through security ACEs) represent approximate hardware
boundaries set when a template is selected. If a section of a hardware resource is full, all processing overflow is sent to
the CPU, seriously impacting switch performance.
Dual IPv4 and IPv6 SDM Default Template
You can select an SDM template to support IP Version 6 (IPv6) switching. The dual IPv4 and IPv6 template allows the
switch to be used in dual-stack environments (supporting both IPv4 and IPv6). Using the dual-stack templates results in
less TCAM capacity allowed for each resource. You should not use this template if you plan to forward only IPv4 traffic.
These SDM templates support IPv4 and IPv6 environments:
 Dual IPv4 and IPv6 default template—Supports Layer 2, QoS, and ACLs for IPv4; and Layer 2, IPv6 host, and ACLs
for IPv6.
 Dual IPv4 and IPv6 routing template—Supports Layer 2, multicast, routing (including policy-based routing), QoS, and
ACLs for IPv4; and Layer 2, routing, and ACLs for IPv6.
Resource Default IPv4 Routing Dual-Default Dual-Routing
Unicast MAC addresses 16 K 16 K 16 K 16 K
IPv4 IGMP or IPv6 groups 1K IPv4 1K IPv4 1K IPv4
1K IPv6
1K IPv4
1K IPv6
Direct routes 16K IPv4 16K IPv4 4K IPv4
4K IPv6
4K IPv4
4K IPv6
Indirect routes 2K IPv4 8K IPv4 1.25K IPv4
1.25K IPv6
2K IPv4
3K IPv6
IPv4 or IPv6 policy-based routing ACEs 0.125K (IPv4
PBR)
0.5K (IPv4
PBR)
0.25K (IPv4 PBR)
0.25K (IPv6 PBR)
0.125K (IPv4 PBR)
0.125K (IPv6 PBR)
IPv4 or IPv6 QoSACEs 1.875K (IPv4
QoS)
0.5K (IPv4
QoS)
0.5K (IPv4 QoS)
0.375K (IPv6
QoS)
0.5K (IPv4 QoS)
0.125K (IPv6
QoS)
IPv4 or IPv6 port or MAC security ACEs 1.875K (IPv4
ACL)
1K (IPv4
ACL)
0.75K (IPv4 ACL)
0.375K (IPv6 ACL)
0.625K (IPv4 ACL)
0.125K (IPv6 ACL)
Resource Default
Unicast MAC addresses 16 K
IPv4 IGMP or IPv6 groups 1K IPv4/1K IPv6
Direct routes 4K IPv4/4K IPv6
Indirect routes 1.25K IPv4/1.25K IPv6
IPv4 or IPv6 policy-based routing ACEs 0.25K (IPv4 PBR)/0.25K (IPv6 PBR)
IPv4 or IPv6 QoSACEs 1K (IPv4 QoS)/0.25K (IPv6 QoS)
IPv4 or IPv6 port or MAC security ACEs 1K (IPv4 ACL)/0.25K (IPv6 ACL)
