Cisco SPA 501G Administration Guide

Cisco SPA 500 Series and Wireless IP Phone Field Reference
Info Tab
Cisco SPA 500 Series and WIP310 IP Phone Administration Guide 199
B
Broadcast Bytes Recv Total number of broadcast bytes received and
processed.
Broadcast Pkts Dropped Total number of broadcast packets received but not
processed. Most codecs can handle up to 5% random
packet drops as long as the packets are random and
not in groups of two or more. Concurrent packet drops
result in voice quality issues.
Broadcast Bytes Dropped Total number of broadcast bytes received but not
processed.
RTP Packets Sent Total number of RTP packets sent (including redundant
packets).
RTP Bytes Sent Total number of RTP packets received (including
redundant packets).
RTP Packets Recv Total number of RTP bytes sent.
RTP Bytes Recv Total number of RTP bytes received.
SIP Messages Sent Total number of SIP messages sent (including
retransmissions).
SIP Bytes Sent Total number of SIP messages received (including
retransmissions).
SIP Messages Recv Total number of bytes of SIP messages sent (including
retransmissions).
SIP Bytes Recv Total number of bytes of SIP messages received
(including retransmissions).
External IP External IP address used for NAT mapping.
Operational VLAN ID ID of the VLAN currently in use
if applicable.
NOTE Not applicable to WIP310.
Parameter Description
