Cisco SPA 501G Administration Guide

Customizing Cisco SPA and Wireless IP Phones
Configuring Phone Features
Cisco SPA 500 Series and WIP310 IP Phone Administration Guide 57
3
Configuration Example
You want to configure the Cisco SPA 525G phone with softkey that, when
pressed, dials the Sales Department’s extension (200). You want this button to
display on the far lower left of the screen when the phone is idle, when the phone
is off hook, or when the phone is connected on a call. You want the outbound call
(that is going to the speed dial) to originate from the second extension on the
user’s phone, not the primary extension.
STEP 1 Log in to the web administration interface.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
STEP 4 In the Programmable Softkeys section, edit the following:
• Programmable Softkey Enable: yes
• PSK1: fnc=sd;ext=200@$PROXY;vid=2;nme=Sales
• Idle Key List: Edit the field to add psk1|1 to the beginning of the string; for
example:
psk1|1;em_login;acd_login;acd_logout;avail;unavail;
redial;dir;cfwd;dnd;lcr;pickup;gpickup;unpark;em_logout;
• Off Hook Key List: Edit the field to add psk1|1 to the beginning of the string;
for example:
psk1|1;option;redial;dir;cfwd;dnd;lcr;unpark;pickup;
gpickup;
• Connected Key List: Edit the field to add psk1|1 to the string, editing the
existing
softkeyname |1 to PSK1. For example, the original string:
hold|1;endcall|2;conf|3;xfer|4;bxfer;confLx;xferLx;park;p
hold;flash;
becomes:
psk|1;hold|2;endcall|3;conf|4;xfer;bxfer;confLx;xferLx;
park;phold;flash
STEP 5 Click Submit All Changes. The “Sales” speed dial softkey is displayed in the lower
left of the screen when the phone is idle, when the phone is connected on a call,
and when the phone is off hook.
