Cisco SPA 501G Administration Guide

Cisco SPA 500 Series and Wireless IP Phone Field Reference
Phone Tab
Cisco SPA 500 Series and WIP310 IP Phone Administration Guide 257
B
Lightweight Directory Access Protocol (LDAP) Corporate
Directory Search
NOTE Does not apply to the WIP310.
If using Active Directory with authentication set to MD5, you must first configure
the following:
• Click the System tab. In the Optional Network Configuration section, under
Primary DNS, enter the IP address of the DNS server.
• In the Optional Network Configuration section, under Domain, enter the
LDAP domain.
Parameter Description
LDAP Dir Enable Choose yes to enable LDAP.
LDAP Corp Dir Name Enter a free-form text name, such as “Corporate
Directory.”
LDAP Server Enter a fully qualified domain name or IP address of
LDAP server, in the following format:
nnn.nnn.nnn.nnn
LDAP Auth Method Select the authentication method that the LDAP
server requires. Choices are:
• None—No authentication is used between the
client and the server.
• Simple—The client sends its fully-qualified
domain name and password to the LDAP server.
May present security issues.
• Digest-MD5—The LDAP server sends
authentication options and a token to the client.
The client returns an encrypted response that is
decrypted and verified by the server.

Cisco SPA 501G Specifications

General

Brand	Cisco
Model	SPA 501G
Category	IP Phone
Language	English
