Cisco SPA 501G Administration Guide

Customizing Cisco SPA and Wireless IP Phones
Configuring Lightweight Directory Access Protocol (LDAP) for the Cisco SPA 500 Series
Cisco SPA 500 Series and WIP310 IP Phone Administration Guide 70
3
Parameter Description
LDAP Corp Dir Name Enter a free-form text name, such as “Corporate
Directory.”
LDAP Server Enter a fully qualified domain name or IP address of
LDAP server, in the following format:
nnn.nnn.nnn.nnn
Enter the host name of the LDAP server if the MD5
authentication method is used.
LDAP Auth Method Select the authentication method that the LDAP
server requires. Choices are:
• None—No authentication is used between the
client and the server.
• Simple—The client sends its fully-qualified
domain name and password to the LDAP server.
May present security issues.
• Digest-MD5—The LDAP server sends
authentication options and a token to the client.
The client returns an encrypted response that is
decrypted and verified by the server.
LDAP Client DN Enter the distinguished name domain components
[dc] ; for example:
dc=cv2bu,dc=com
If using the default Active Directory schema
(Name(cn)->Users->Domain), an example of the
client DN follows:
cn="David Lee",dc=users,dc=cv2bu,dc=com
LDAP Username Enter the username for a credentialed user on the
LDAP server.
LDAP Password Enter the password for the LDAP username.
LDAP Search Base Specify a starting point in the directory tree from
which to search.
Separate domain components [dc] with a comma.
For example:
dc=cv2bu,dc=com

Cisco SPA 501G Specifications

General

Brand	Cisco
Model	SPA 501G
Category	IP Phone
Language	English
