Output Assignments for AES67 Source Audio Streams
When streaming in AES67 mode, the hard coded Matrix Editor output channel assignments
depend on the stream configuration mode, as displayed in the following table.
Verify audio is displayed on the PPMs in the Sources panel before commencing AES67 streaming.
23.9 Monitoring PPMs
8 PPMs on front panel display 4 channel inputs/outputs or
encoders/decoders
Capable of monitoring 4 inputs, 4 outputs, 4 encoders and 4
decoders simultaneously
Gateway 8 has 8 PPMs on codec front panel capable of
monitoring 8 inputs, 8 outputs, 8 encoders or 8 decoders;
Gateway 16 capable of monitoring 16 inputs, 16 outputs, 16
encoders or 16 decoders
Gateway 8 capable of monitoring 8 inputs, 8 outputs, 8 encoders
or 8 decoders simultaneously; Gateway 16 capable of monitoring
16 inputs, 16 outputs, 16 encoders and 16 decoders
simultaneously.
