54 Gateway and Gateway 4 Manual v1.2
© Tieline Research Pty. Ltd. 2021
program. If the default value Any is used then a call will be routed to an audio stream on a
first-come-first-served basis in a multi-stream program.
10. Press the Return button to exit the menu and select Save in the dialog to store new
settings. Note: to enable an interface after configuration press the button and select
Enable in the onscreen dialog.
20.2 Configuring SIP Accounts
Getting Started
Up to 16 SIP accounts can be configured and registering codecs for SIP connectivity is simple.
First, select the SIP server to which the codec will be registered. On a LAN this may be your own
server, or it could be one of the many internet servers available. When registering an account with a
SIP server you will be provided with:
· The SIP registrar and Proxy Server details.
· An authorized user or username (often the same as a SIP number).
· A password.
· Domain details.
· Realm details (in most cases leave blank).
· Registration Timeout (this shouldn't need to be adjusted from the default setting).
Important Notes:
· In most situations it is best to configure a SIP account when the codec is configured with
a public IP address.
· Each SIP account can only be mapped to a single SIP interface, i.e. SIP1 (LAN1) or SIP
2 (LAN2).
· Up to 16 SIP accounts can be added to the codec.
· It is also possible to add and register a SIP account to your codec using the HTML5
Toolbox Web-GUI.
Adding a SIP Account
1. Press the SETTINGS button, then navigate to SIP and press the button.
2. Navigate to SIP Accounts and press the button.
