Important Notes:
· When you decide to use an existing program as a template, the new program inherits
all the settings of the template program and you can adjust these settings as required
by continuing through the program wizard.
· Gateway 16 channel codecs support simultaneously receiving up to 16 separate
multicast streams in multicast client mode.
3. To configure new program level rules click the drop-down arrow and select the preferred option
Important Notes for Rules:
· The Gateway 4 codec has 8 hardware GPIOs and 56 logical outputs, and the Gateway
8/16 has 16 hardware GPIOs and 48 logical outputs; both codecs also have 3 virtual
inputs, and 64 WheatNet Logic Inputs/Outputs. (WheatNet logic I/Os allow Tieline
WheatNet-IP enabled codecs to activate functions across a WheatNet-IP network.
WheatNet logical inputs are only available if a codec has a WheatNet-IP card installed).
See Enabling Relays & RS232 Data for more info.
· Virtual inputs 5-7 can be activated by pressing the F1 button and KEYPAD buttons 1-3.
· A non-WheatNet-IP Tieline codec can be configured to trigger a WheatNet LIO in a
Tieline WheatNet-IP codec.
· Tieline WheatNet-IP codecs require Wheatstone Razor firmware version 1.4.22 or later
to support WheatNet LIOs. In addition, the WheatNet-IP codec must have the WNet
Enable LIO checkbox selected in the Options panel of the HTML5 Toolbox Web-GUI.
· Relay reflection is not available for SIP and Multicast Client programs.
· Connection-related rules are not displayed in Answer only audio streams.
· Program level rules intended to activate dialing are not valid in Answer only programs or
audio streams.
· For more details about rules see Creating Rules.
