VLAN ID (VLAN configuration only)
The VLAN ID is encapsulated in IP packets to facilitate routing throughout your network.
1. Press the SETTINGS button.
2. Use the navigation buttons on the front panel to select Transports and press the button.
3. Use the down navigation button to select a VLAN interface and press the button.
4. Navigate to Configuration and press the button.
5. Select Usage and press the button.
6. Select the mode of operation for this VLAN (e.g. Control & Streaming, Streaming only,
Control Only) and press the button.
7. Use the down navigation button to scroll to VLAN ID.
8. Press the button to enter a number between 1-4094 inclusive.
9. Press the button to confirm this setting.
10. Press the Return button, then select Yes in the confirmation dialog and press the
button to confirm the new settings.
VLAN Priority (VLAN configuration only)
VLAN Priority is a prioritization scheme for forwarding data packets throughout Virtual LANs.
1. Press the SETTINGS button.
2. Use the navigation buttons on the front panel to select Transports and press the button.
3. Use the down navigation button to select a VLAN interface and press the button.
4. Navigate to Configuration and press the button.
5. Select Usage and press the button.
6. Select the mode of operation for this VLAN (e.g. Control & Streaming, Streaming only,
Control Only) and press the button.
7. Use the down navigation button to scroll to VLAN Priority.
8. Press the button to enter a number from 0 to 7 inclusive.
9. Press the button to confirm this setting.
10. Press the Return button, then select Yes in the confirmation dialog and press the
button to confirm the new settings.
VLAN Interface (VLAN configuration only)
This setting applies the VLAN settings to a physical Ethernet port in the codec.
1. Press the SETTINGS button.
2. Use the navigation buttons on the front panel to select Transports and press the button.
3. Use the down navigation button to select a VLAN interface and press the button.
4. Navigate to Configuration and press the button
5. Select Usage and press the button.
6. Select the mode of operation for this VLAN (e.g. Control & Streaming, Streaming only,
Control Only) and press the button.
7. Use the down navigation button to scroll to Interface.
8. Press the button to select LAN1 or LAN2, then press the button.
9. Press the Return button, then select Yes in the confirmation dialog and press the
button to confirm the new settings.
