Outputs Panel
Feature
Description
1
Settings
Select analog or digital as the output type. Note: configure
the global digital output type via Setting > Audio Options >
Dig.Output Type > [select AoIP or AES3].
2
Send/Return slider
Use the Send/Return slider to adjust the balance between
the mix of incoming (return/decoder) audio and outgoing
(send/input) audio fed to each codec output
3
Output PPM meter
Output PPM meter
4
Send/Return indications
Balance of send and return audio included in the mix for
each output (expressed as a percentage)
5
Close button
Click to close the panel
