8
-
48
DK4220/4520/4720/5020/5320/5520/6020
2. Disconnect the connector and
loosen the nut from the bottom of
the fender to remove the turn sig-
nal lamp assembly.
(1) Connector (2) Nut
TD2O742A
3.
Loosen the screw to remove the cover.
TD2O741A
(1) Screw (2) Cover
TD2O743A
(1) Turn Signal Lamp (2) Position Lamp
4. Turn the socket counterclockwise
to remove the bulb and replace it
with a new one.
