PARKING
1. Place the main shift lever to the
"Stop" position.
2. Set the range shift lever to the
"Neutral" position.
3. Apply the parking brake.
4. Stop the engine and remove the
key.
(1) Parking Brake Lever
(2) Parking Brake Pedal (3) Stopper
(A) Depress (B) Lock
2
A
3
1
2
A
B
B
3
1
cf1O612a
Operate the parking brake as follows:
1. To lock the parking brake pedal,
depress it rmly and lock it with the
parking brake lever.
2. To release it, depress the parking
brake pedal rmly again.
CHOCKING THE CRAWLERS
d85O615a
• Parking on uphill road: behind the
crawlers
• Parking on downhill road: in front of
the crawlers
(1) Chock
When stopping the combine
harvester, stop it on safe and
level ground, lower the reaping
unit, stop the engine and apply
the parking brake.
•
CAUTION
