(1) Hour Meter
HOUR METER
This indicates the amount of hours of
operation at the rated engine RPM.
124 hours
0 0 1 2 4
(1) Tachometer
TACHOMETER
This indicates the engine revolutions
per minutes.
cf1O435Acf1O434A
cf1O437A
COOLANT TEMPERATURE LAMP
When the engine coolant is exces-
sively hot, this warning lamp blinks
and the horn sounds at an interval.
To check the coolant, wait until the
engine is cooled down. Then, open
the radiator pressure cap slowly.
You can get burnt if opening it
abruptly.
•
CAUTION
The minute can be obtained by
multiplying the fifth number to
the right by 6.
[Example] 12.4HR………12:24
•
•
NOTE
