INSTALLATION AND REMOVAL
22 111
CF1O832B
1. Open the threshing cylinder side
cover.
(1) Concave
(2) Threshing Cylinder Side Cover
3
3
4
1
2
3
3
4
1
2
A
A
A
A
A
A
A
A
CF1O833B
(1) Back Side Of Concave
(2) Front Side Of Concave (3) Screw
(4) Threshing Unit Top Cover
(A) Pull Up
2. Open the threshing unit top cover.
3. Loosen the screw and pull up the
concave to remove it.
REMOVING/INSTALLING SIEVE
CASE
The front section and rear
section of the concave are dif-
ferent in length. Make sure to
install it in the correct orienta-
tion.
•
CAUTION
As the sieve case is heavy,
its installation and removal
should be performed by two
or more people.
•
CAUTION
