The work load of the threshing unit is
indicated by a square shaped lamps
and "LOAD" lamp as shown on the
next page.
More illuminated lamps indicates that
higher load is applied to the thresh-
ing
unit.
HOW TO WORK ACCORDING TO THE LOAD LAMPS
cf1O450A
LOAD LAMP LEVEL 1
LOAD LAMP LEVEL 2 LOAD LAMP LEVEL 4
cf1O451A
cf1O452A
Load lamp + 1 lamp illuminated: accel-
eration possible
Load lamp + 2 lamps illuminated:
current speed appropriate
Load lamp + 4 lamps illuminated: im-
mediate
deceleration required
LOAD LAMP LEVEL 3
cf1O452A
Load lamp + 3 lamps illuminated: de-
celeration desired
Select the appropriate vehicle
speed according to the indi-
cation by the load lamps and
perform reaping operation
manually within the load level
1 or 2 range. Otherwise, the
engine and other parts can be
prematurely worn out.
•
CAUTION
