Adjusting di-
rection
S
ymptom (condition)
UP
L
ower
• Excessive grain loss
• Poor separation
quality
•
Crops with high
moisture content
•
Excessive weeds
• Unripe crops
(1) Dust Discharge
Cover
(2) Dust Discharge
Control Plate
(3) Wing Nut
(4) Hole
(C) Upper
(D) Lower
(E) Adjusting
(F) Longer Side
11
2
4
3
E
C
D
2
4
3
E
F
F
C
D
cf1O735a
cf1O730a
(1) Discharge Control
Plate (Inside tank)
(2) Nut
(3) Grain Tank
(A) Front
(B) Rear
(C) Highest Position
(D) Lowest Position
(E) Adjusting
GRAIN TANK
ADJUSTING DISCHARGE CON-
TROL PLATE
3
2
C
D
E
3
2
C
D
E
cf1O736a
2
C
D
E
2
C
D
E
11
cf1O737B
When reaping watery or unripe
crops or there is a lot of weeds,
select the lower position to pre-
vent clogging and excessive
grain loss.
If there is a lot of grains or straw
debris left on the sieve case
slide, adjust the dust discharge
c
ontrol plate downwards. Oth-
erwise, the unit can be clogged,
leading to increase in grain loss.
•
•
NOTE
A
B
