Perform this procedure with 2 to 3
people.
1. Have another person turn the
rocker bracket with a hand to
place the net in the position in
which the net can be pulled out
from the left clean-out.
2. Remove the nut and plain washer
that x the net.
3. Pull out the left clean-out of the
grain sieve.
4.
Install a new grain sieve in the re-
verse order of removal.
As the mounting plate and sieve
case auxiliary plate are con-
nected to the net, they can be
removed with the net by remov-
ing the nut and plain washer.
When installing the removed
sieve case auxiliary plate, make
sure to install it in the correct ori-
entation.
•
•
NOTE
5. Adjust the sieve case auxiliary
plate 2, replace the grain sieve,
and install the left and right clean-
out covers.
6. Install the left covers (2 & 3) of
the threshing unit. Then, close the
grain tank.
ADJUSTING DUST DISCHARGE
CONTROL PLATE
1. Loosen the wing nut.
2. Move the dust discharge control
plate to adjust it.
The dust discharge control plate
is located behind the dust dis-
charge cover.
•
NOTE
The standard (default) position of
the dust discharge control plate is
as follows:
The dust discharge control plate
can be located in the center by
placing the shorter section from
the tip of the plate to the hole
downward.
•
NOTE
