THROTTLE LEVER
(1) Throttle Lever
This lever controls the engine speed.
Position to select the engine idle speed
Position to select for work
111
cf1O442A
RANGE SHIFT LEVER
(1) Range Shift Lever
(A) M: Standard (harvesting)
(B) H: Driving (C) L: Low Speed
Operate the range shift lever to se-
lect the desired position between
"Driving," "Standard" and "Low
speed." For harvesting, place the
lever in the "Driving" or "Standard"
position.
Operate the range shift lever
only after setting the main
shift lever in the "N" (Neutral)
position and stopping driving.
•
CAUTION
1
A
B
C
1
A
B
C
cf1O408A
For shifting, operate the lever
to the correct position accord-
ing to the indication on the de-
cal.
•
CAUTION
Do not place the main shift
lever in any position other
than the "N" (Neutral) position
while the parking brake is ap-
plied. Operating the machine
with the parking brake applied
can cause malfunction.
•
IMPORTANT
