If the crawler's tension is ex-
cessive, the engine power and
driving section durability can
be deteriorated. Make sure
to set the tension within the
specied range.
•
CAUTION
ADJUSTING EACH BELT LENGTH
Adjust the adjusting bolt and cable adjusting bolt so that the spring mounting
length of the belt is within the specied range in the following table:
(※) : Cabin model only
No. Belt Specication Quantity
Spring mount-
ing length
(mm)
Area
around
engine
A Transmission drive belt COKE
SC-65 2 215~219
B Threshing drive belt S
B-55 3 275~279
C
Reaping unit reversing
belt-1
B
59 1 119~121
D
Reaping unit reversing
belt-2
LB
-43.75 1 125~127
Around
reaping
unit
E Reaping belt S
B-54 1 123~127
F Reel drive belt LB
-107 1 217~219
Around
threshing
unit
G Threshing belt 2 C
70 2 144~148
H Blower belt C
47 1 124~128
I No. 1 drive belt B
104.25 145~148
J Rocker drive belt B
66 120~126
Others K Straw separator drive belt C
64.5 1 118~122
