1. Grease the moving parts of the un-
loader before long-term storage.
2. Grease it during disassembly.
After adding grease to the un-
loader cases 1 and 3, open the
cleaning-out and wipe grease
coming out of the inside thor-
oughly.
•
CAUTION
CF1O809B
DRIVING SYSTEM
1. Add grease and oil to the grease application point of the track roller section
before long-term storage or disassembly/assembly.
2. When tightening the ller hole mounting bolt, tape it for 2 to 3 turns.
(1) Grease Nipple (Idle Roller Section) (2) Grease Nipple (Track Roller Section)
(3) Grease Nipple (Tension Roller Section)
Apply grease to the track roller only when replacing the roller, bear-
ings or shafts or servicing the internal part.
If an excessive amount of grease is applied, water may enter the
seal, causing damage of the roller.
•
•
CAUTION
To Next Page
