sYMpToM Cause inspeCTion iTeM soluTion
1. Excessive
load at front
of reaping
unit
The reel spins too quickly. R
eel drive belt
Stop operation temporarily, place the reaping clutch
lever in the OFF position and lower the reel speed.
The reel tine is stretched too deep-
ly into crops.
R
eel lifting/lowering
switch
Stop operation temporarily, place the reaping clutch
lever in the OFF position and lift the reel.
The reel tine's angle is too wide. R
eel tine
Stop operation temporarily, place the reaping clutch
lever in the OFF position and decrease the angle of
the reel tine.
The reel angle is not suitable to
the reaping conditions.
R
eel lifting/lowering
switch
Stop operation temporarily, place the reaping clutch
lever in the OFF position and adjust to the proper
position.
2.
Crops are
accumulated
in the reaping
unit.
The reel height is not suitable to
the reaping conditions.
R
eel lifting/lowering
switch
Stop operation temporarily, place the reaping clutch
lever in the OFF position and adjust to the proper
position.
The reel speed is low. R
eel drive belt
Stop operation temporarily, place the reaping clutch
lever in the OFF position and increase the reel speed.
The gap between the auger and
bottom panel is too wide.
Auger
St
op operation temporarily, stop the engine and adjust
the gap properly.
The gap between the feeding drum
and bottom panel is too wide.
Feeding drum height
S
top operation temporarily, stop the engine and lower
the feeding drum.
3. The reaping
unit does not
cut crops but
rather pushes
them aside.
Foreign materials (roots, straw,
mud, pebbles, etc.) are stuck to
the cutting blades or conveying
section.
Cutting blade and
conveying section
S
top operation temporarily, stop the engine and
remove foreign materials. Then, check the cutting
blades and conveying section again.
The reaping drive belt is sliding.
R
eaping drive belt
Stop operation temporarily, stop the engine and re
-
place it.
R
eaping drive belt
tension spring
St
op operation temporarily, stop the engine and adjust
the tension.
TroubleshooTing for reaping uniT
